ML with FITS¶

User Guide for torchfits.data: choose a Dataset, preprocess with torchfits.transforms, load with make_loader, train a small model. API details stay in the Data module reference.

make_loader wraps torch.utils.data.DataLoader and can warm the handle cache when the dataset exposes .files. Use a plain DataLoader when you already own collate_fn / persistent_workers. See example_make_loader_vs_dataloader.py.

End-to-end: Galaxy Zoo morphology¶

Train a tiny CNN on real FITS: Galaxy Zoo 1 labels + Legacy Survey cutouts.

bash scripts/fetch_example_samples.sh   # caches GalaxyZoo1_DR_table2.fits
# first run also downloads ~200 Legacy Survey cutouts (~10–20 MB)
pixi run python examples/example_ml_galaxyzoo_legacy.py
# copy examples/output/ml_gz_class_grid.png → docs/assets/gallery/ when refreshing

from torchfits.data import FitsImageDataset, make_loader
from torchfits.transforms import (
    ArcsinhStretch,
    BackgroundSubtract,
    Compose,
    ZScaleNormalize,
)

# labels from GZ1 FITS; paths from Legacy Survey fits-cutout downloads.
# The example prepends NanToZero for off-footprint NaNs before this Compose.
pipeline = Compose(
    [BackgroundSubtract(), ArcsinhStretch(a=0.1), ZScaleNormalize()]
)
dataset = FitsImageDataset(paths, hdu=0, labels=labels, transform=pipeline)
loader = make_loader(dataset, batch_size=16, num_workers=0, optimize_cache=False)

model = TinyCNN()  # two Conv2d + Linear, defined in the example script
optimizer = torch.optim.Adam(model.parameters(), lr=1e-3)
loss_fn = torch.nn.CrossEntropyLoss()

for images, batch_labels in loader:
    optimizer.zero_grad()
    loss = loss_fn(model(images), batch_labels)
    loss.backward()
    optimizer.step()

The script runs one full epoch on CPU, prints loss / accuracy, and writes a Lupton RGB sample grid of the cutouts.

1. table.read the GZ1 catalog; keep UNCERTAIN == 0 and spiral or elliptical.
2. Download LS FITS cutouts into ~/.cache/torchfits/samples/gz_legacy_cutouts/.
3. FitsImageDataset + Compose([NanToZero, BackgroundSubtract, ArcsinhStretch, ZScaleNormalize]).
4. make_loader(..., batch_size=16).
5. Train TinyCNN for one epoch; print metrics.

Script: example_ml_galaxyzoo_legacy.py. TORCHFITS_EXAMPLE_FAST=1 skips (exit 0) when cutouts are not cached.

Survey mosaic cutouts: CFHT MegaPipe¶

Public CFHTLS D1 IQ MegaPipe stacks (~20k×21k float32, ~1.74 GB/band, uncompressed) plus a SExtractor catalog with pixel X_IMAGE/Y_IMAGE.

bash scripts/fetch_cfht_megapipe_sample.sh   # ~5.3 GB once
# optional: MEGAPIPE_N_CUTOUTS=50 for a quick local smoke
pixi run python examples/example_megapipe_cutout_collage.py
# copy examples/output/megapipe_cutout_collage.png → docs/assets/gallery/ when refreshing

The example:

1. Selects 64 gallery stamps with MAG_AUTO ∈ [17, 22].
2. Reads matching G/R/I windows with open_subset_reader.
3. Builds Lupton RGB (Q=8, stretch=5) into an 8×8 collage (512×512).
4. Times 1000 random 64×64 boxes (one subprocess per backend; setup+warm outside the timer; peers force owned copies).

Indicative timing on this machine (1000×64×64, G band, uncompressed float32):

open_subset_reader maps the uncompressed data segment once and does row slice + endian swap into a torch tensor — same class of work as fitsio / Astropy memmap cutouts, with CFITSIO only on the fallback path (compressed / scaled / non-2D). Prefer it over repeated read_subset for many windows from one mosaic. Rice .fz / full-HDU / GPU numbers stay on the scorecards.

Script: example_megapipe_cutout_collage.py.

Choosing a Dataset¶

Full signatures: Data module.
